RT Series 5/6/8/10 kVA Single Phase UPS, 10/15/20 kVA

Product available regions

For region-specific product details and variations in specifications, please download the local leaflet or visit the local website.
Ext: RT 5-10 kVA Extended Runtime Model
Std: RT 5-10 kVA Standard Runtime Model
208 V: RT 5-10 kVA, 208 V
3P: RT 10-20 kVA, 3-Phase

Product Introduction
Features & Benefits
Availability & Flexibility

• True online double-conversion topology and zero transfer time to battery provides 24/7 full-time protection
• Wide input voltage range allows the UPS to operate in harsh electrical environments and extends battery life
• AC-start function allows the UPS to be switched on without connecting to a battery
• Programmable load bank disconnects non-critical loads when a blackout occurs and reserves more battery power for critical loads
• Up to four units parallel capacity allows redundancy and load expansion  (Apply to 5-10kVA)
• Hot swappable batteries ensure continuous operation even when batteries are being replaced
• VRLA and Li-ion External Battery Cabinet (EBC) are available for scalable runtime
• Flexible battery quantity configuration enables optimized battery investment. And when one battery fails, it could be removed without replacing the entire battery string, reducing maintenance cost and efforts
• The Power Distribution Box (PDB) and Maintenance Bypass Breaker (MBB) are optional respectively for easy configuration and easy UPS replacement
• The rRPP (Rack Remote Power Panel), which can be integrated with standard server racks, simplifies power output distribution and power monitoring
• Common battery configuration is supported in RT 15/20kVA parallel mode to save installation space and additional battery costs

Efficiency & Reliability

• Unity output power factor guarantees no de-rating with loads and provides permanent 100% kW
• Best-in-class AC-AC efficiency of up to 96.5% and 99% in ECO mode lowers energy costs
• Automatic fan speed control maximizes system efficiency and significantly reduces audible noise and prolongs battery life
• Fan failure detection sends early warnings to facilitate predictive maintenance of UPS

Manageability

• Intelligent battery management to extend battery life and maximize battery performance. The battery aging detection monitors battery status for predictive maintenance, and the 3-stage charging mechanism keeps the battery from continuous float charging during the intermission stage to prolong battery life
• Excellent local management through a user-friendly graphical and multi-lingual LCD display
• Various types of communication interfaces, including USB, RS-232, and RS-485 ports, mini slot, REPO/ROO for remote management, and in-built dry contacts for monitoring and notification of system operation conditions
• UPS management software such as ShutdownAgent and InfraSuite Device Manager allow users to monitor UPS status and protect critical devices
